Trynox sanitary Diaphragm Valve Branch Type

SKU:
TAVA3WC
UPC:
7453017301500
On Sale
  • Trynox sanitary Diaphragm Valve Branch Type
  • Trynox sanitary Diaphragm Valve Branch Type
  • Trynox sanitary Diaphragm Valve Branch Type
$327.60 - $471.59

Description

Diaphragm Valves:

Consists of a valve body with two or more ports, a diaphragm, and a "weir or saddle" or seat upon which the diaphragm closes the valve. The valve is constructed from either plastic or metal.

The diaphragm seal is a flexible membrane that form a positive closure when it is compressed against the weir usually made by elastomeric material or PTFE filled with elastomeric like EPDM or VITON.

Sanitary Valves

Valves are process components that provide dynamic seals within the process. Is a device that regulates, directs or controls the flow of a fluid (gases, liquids, fluidized solids, or slurries) by opening, closing, or partially obstructing various passageways. Valves are technically fittings, but are usually discussed as a separate category. In an open valve, fluid flows in a direction from higher pressure to lower pressure. They also provide seals between the process and the atmosphere.

Stabilize and Control Your Operation

Our Trynox Sanitary Diaphragm Valve Branch Type works well in assisting fluid control in the food, beverage, biotech, pharmaceutical, and other industries requiring hygienic practices.

  • Durable, high-quality Trynox material comes standard
  • Fits to sanitary stainless steel tubing
  • Surface finishing 180 Grit ID/150 Grit OD
  • Maximum operating pressure rating of 140 psi (depending on valve size) at 70 degrees Fahrenheit ambient temperature

Regardless of your business vertical, Chemseal can handle the complexity of the task. We carry many specialized sanitary stainless steel fittings including our Trynox Sanitary Diaphragm Valve Branch Type. Effectively control your operation with our Trynox Sanitary Diaphragm Valve Branch Type, which will exceed your stainless steel sanitary needs in virtually any industry. As a premier integral solutions provider, we’re proud to bring you the best quality sanitary stainless steel valves and other sanitary fittings that will add value to your fluid operation.

SPECS:

  • Trynox TAVA3WC sanitary diaphragm valve branch type
  • 1” x ¾”, 1.5” x 1” and 2” x 1.5” sizes
  • 316L grade

Tri-Clamp Sizing Guide

Tri-Clamp Fittings and Gasket Sizing Guide

Sanitary Fitting Dimensions



Sanitary SizeOD of Flange EndID of TubeOD of Tube
1/2″ 0.992 0.370 0.500
3/4″ 0.992 0.620 0.750
1″ 1.984 0.870 1.000
1 1/2″ 1.984 1.370 1.500
2″ 2.516 1.870 2.000
2 1/2″ 3.047 2.370 2.500
3″ 3.579 2.870 3.000
4″ 4.682 3.834 4.000
6″ 6.562 5.782 6.000
8″ 8.602 7.782 8.000

Tubing Dimensional Tolerances

A-270 Sanitary Tubing Dimensional Tolerances

Tubing



A tube, or tubing, is a long hollow cylinder used for moving fluids (liquids or gases)

For Beverage & Sanitary stainless steel tubing for the Brewery, Food, Dairy and Pharmaceutical Industries must be manufactured in 304L & 316L polished on the ID to 20u-in Ra/OD to 30u-in Ra, Following standards like ASTM A-269; A-270, DIN 11805 or ENxxxxx

All dimensions in inches (mm)

Size OD

Wall Thickness

Outside Diameter

Length

Wall

1" (25.4)

0.065" (1.65)/0.049" (1.25)

+/-0.005 (0.13)

+1/8" (3.18)

- 0 +/-10.0%

1-1/2" (38.1)

0.065" (1.65)/0.049" (1.25)

+/-0.008 (0.20)

+1/8" (3.18)

- 0 +/-10.0%

2" (50.8)

0.065" (1.65)/0.049" (1.25)

+/-0.008 (0.20)

+1/8" (3.18)

- 0 +/-10.0%

2-1/2" (63.5)

0.065" (1.65)

+/-0.010 (0.25)

+1/8" (3.18)

- 0 +/-10.0%

3" (76.2)

0.065" (1.65)

+/-0.010 (0.25)

+1/8" (3.18)

- 0 +/-10.0%

4" (101.6)

0.083" (2.11)

+/-0.015 (0.38)

+1/8" (3.18)

- 0 +/-10.0%

Gasket Compatibility Chart

Sanitary Gaskets General Performance Properties



Nitrite (Buna)

Fluoro-Elastomer(Viton)

Platinum Cured Silicone Elastomer

Ethylene-Propylene Diene Monomer(EPDM)

PolyTetra Fluoro Ethylene(Teflon)

Tufsteel

Letter Designation

SFY

PX

EPDM

GTS

Sanitary Gasket Color Code

RED

Yellow & White

Pink

Green

Remains White

Remains Grey

Max Temperature Intermittent

240Deg F

410Deg F

580Deg F

300Deg F

450Deg F

578Deg F

Max Temperature Continuous

210Deg F

380Deg F

490Deg F

260Deg F

400Deg F

526Deg F

Minimum Temperature

-65

-20

-85

-70

-350

-370

USP Class VI

No

Yes

Yes

Yes

Yes

Yes

Steam in Place Performance

Poor

Good

Good

Good

Good

Excellent

Acids, Dilute

Good

Excellent

Good

Good

Excellent

Excellent

Alkalies

Good

Good

Excellent

Excellent

Excellent

Excellent

Alcohol, Glycols

Excellent

Good

Excellent

Excellent

Excellent

Excellent

Animal Oils & Fats

Excellent

Excellent

Good

Fair

Excellent

Excellent

Soaps, Bleaches, Detergents

Fair/Good

Good

Fair

Excellent

Excellent

Excellent

Vegetable Oil

Excellent

Excellent

Excellent

Fair

Excellent

Excellent

Water

Good

Excellent

Good

Excellent

Excellent

Excellent
