Trynox Sanitary SMS 90å¡ Welding Short Elbow

SKU:
T2CWS
UPC:
7453017305072
On Sale
  • Trynox Sanitary SMS 90å¡ Welding  Short Elbow
  • Trynox Sanitary SMS 90å¡ Welding  Short Elbow
  • Trynox Sanitary SMS 90å¡ Welding  Short Elbow
$6.42 - $47.55

Description

A Sanitary SMS 90 Degree Welding Short Elbow Perfect For Your Business

Keep your sanitary fluid processes running efficiently and smoothly with Chemseal’s Trynox Sanitary SMS 90 Degree Welding Short Elbow.

  • Fits to sanitary stainless steel tubing
  • 180 Grit ID/150 Grit OD
  • Maximum operating pressure rating of 200 psi at 70 degrees Fahrenheit ambient temperature
  • High-quality Trynox stainless steel material

This sanitary fitting, or ‘ell,’ welds to tubes at a 90-degree angle to change the direction of flow between tubes. As with most of Chemseal’s fine sanitary fittings, this Trynox Sanitary SMS 90 Degree Welding Short Elbow is made with high-quality, reinforced sanitary stainless steel to ensure hygiene. Control your hygienic product flow today with Chemseal’s great selection of sanitary fittings, sanitary tubing, and Trynox Sanitary SMS 90 Degree Welding Short Elbows.

SPECS:

  • Trynox T2CWS Series 90 Degree Welding Short Elbow
  • 304 or 316L grade
  • 1”, 1.5”, 2”, 2.5”, 3” and 4” sizes



Tri-Clamp Sizing Guide

Tri-Clamp Fittings and Gasket Sizing Guide

Sanitary Fitting Dimensions



Sanitary SizeOD of Flange EndID of TubeOD of Tube
1/2″ 0.992 0.370 0.500
3/4″ 0.992 0.620 0.750
1″ 1.984 0.870 1.000
1 1/2″ 1.984 1.370 1.500
2″ 2.516 1.870 2.000
2 1/2″ 3.047 2.370 2.500
3″ 3.579 2.870 3.000
4″ 4.682 3.834 4.000
6″ 6.562 5.782 6.000
8″ 8.602 7.782 8.000

Tubing Dimensional Tolerances

A-270 Sanitary Tubing Dimensional Tolerances

Tubing



A tube, or tubing, is a long hollow cylinder used for moving fluids (liquids or gases)

For Beverage & Sanitary stainless steel tubing for the Brewery, Food, Dairy and Pharmaceutical Industries must be manufactured in 304L & 316L polished on the ID to 20u-in Ra/OD to 30u-in Ra, Following standards like ASTM A-269; A-270, DIN 11805 or ENxxxxx

All dimensions in inches (mm)

Size OD

Wall Thickness

Outside Diameter

Length

Wall

1" (25.4)

0.065" (1.65)/0.049" (1.25)

+/-0.005 (0.13)

+1/8" (3.18)

- 0 +/-10.0%

1-1/2" (38.1)

0.065" (1.65)/0.049" (1.25)

+/-0.008 (0.20)

+1/8" (3.18)

- 0 +/-10.0%

2" (50.8)

0.065" (1.65)/0.049" (1.25)

+/-0.008 (0.20)

+1/8" (3.18)

- 0 +/-10.0%

2-1/2" (63.5)

0.065" (1.65)

+/-0.010 (0.25)

+1/8" (3.18)

- 0 +/-10.0%

3" (76.2)

0.065" (1.65)

+/-0.010 (0.25)

+1/8" (3.18)

- 0 +/-10.0%

4" (101.6)

0.083" (2.11)

+/-0.015 (0.38)

+1/8" (3.18)

- 0 +/-10.0%

Gasket Compatibility Chart

Sanitary Gaskets General Performance Properties



Nitrite (Buna)

Fluoro-Elastomer(Viton)

Platinum Cured Silicone Elastomer

Ethylene-Propylene Diene Monomer(EPDM)

PolyTetra Fluoro Ethylene(Teflon)

Tufsteel

Letter Designation

SFY

PX

EPDM

GTS

Sanitary Gasket Color Code

RED

Yellow & White

Pink

Green

Remains White

Remains Grey

Max Temperature Intermittent

240Deg F

410Deg F

580Deg F

300Deg F

450Deg F

578Deg F

Max Temperature Continuous

210Deg F

380Deg F

490Deg F

260Deg F

400Deg F

526Deg F

Minimum Temperature

-65

-20

-85

-70

-350

-370

USP Class VI

No

Yes

Yes

Yes

Yes

Yes

Steam in Place Performance

Poor

Good

Good

Good

Good

Excellent

Acids, Dilute

Good

Excellent

Good

Good

Excellent

Excellent

Alkalies

Good

Good

Excellent

Excellent

Excellent

Excellent

Alcohol, Glycols

Excellent

Good

Excellent

Excellent

Excellent

Excellent

Animal Oils & Fats

Excellent

Excellent

Good

Fair

Excellent

Excellent

Soaps, Bleaches, Detergents

Fair/Good

Good

Fair

Excellent

Excellent

Excellent

Vegetable Oil

Excellent

Excellent

Excellent

Fair

Excellent

Excellent

Water

Good

Excellent

Good

Excellent

Excellent

Excellent
